Polcd 2.8'' TFT LCD Customize Color Panel Screen 240*320 Resolution 260 nit IPS LCD Display

Polcd 2.8'' TFT LCD Customize Color Panel Screen 240*320 Resolution 260 nit IPS LCD Display

2.8 inch TFT LCD screen

IPS LCD display 260 nit

240x320 resolution LCD panel

Place of Origin:

Shenzhen, China

Brand Name:

Polcd

Certification:

RoHS, ISO9001

Model Number:

P028H115-10-IPS

Contact Us

Request A Quote
Product Details
Size:
2.8 Inch
Resolution:
240x320
Interface:
4wire SPI
Driver IC:
ST7789V
Brightness (cd/m²):
260 Nit
Viewing Angle:
IPS All View Angle
Payment & Shipping Terms
Minimum Order Quantity
1 piece
Price
Please contact us for latest price
Packaging Details
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Delivery Time
1-7 working days
Payment Terms
T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram
Supply Ability
40,000 PCS per day
Product Description

TFT Display Description:

With IPS full viewing angle and 4-wire SPI interface, this 2.8-inch TFT LCD display offers high-quality and versatile display performance suitable for a range of applications.


Parameter:

Model No. P028H115-10-IPS
Screen Size 2.8 inch
Number of Pixel 240RGB(H)x320(V)
Pin 10 pin
Display area 43.20(H)x57.60(V)mm
Pixel pitch 0.180(H)x0.180(V)mm
Outline Dimension 50.00x69.20x2.30mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally Black
Viewing Direction(eye) ALL
Display Color 262K
Luminance(cd/m2) 260 nit
Contrast Ratio 800:1
Interface 4wire SPI
Back-light LED Side-light type
Drive IC ST7789V
Operation Temperature -20~70 ℃
Storage Temperature -30~80 ℃


Application

This 2.8-inch TFT LCD display with IPS full viewing angle and 4-wire SPI interface is suitable for a variety of fields, including embedded systems, handheld devices, medical equipment, industrial control, and smart homes. The IPS technology ensures clear and vivid visuals from any angle, while the 4-wire SPI interface enables fast data transfer for smooth and efficient performance. Additionally, its compact size makes it an ideal choice for small devices and embedded systems, and the high-quality graphics and sharp resolution provide an exceptional visual experience for various projects. Furthermore, the responsive and intuitive touchscreen interface, along with the wide viewing angle, makes it an excellent display solution for applications that require user interaction.
