Name: Polcd 2.8 inch TFT 240*320 Small Color Screen JD9853 Drive IC Spi interface IPS TFT LCD Display
Brand: Shenzhen P&O Technology Co., Ltd
SKU: P028HK9853-24P
Availability: InStock

Home > products > Custom TFT Displays >

Polcd 2.8 inch TFT 240*320 Small Color Screen JD9853 Drive IC Spi interface IPS TFT LCD Display

240*320 TFT LCD Display

TFT Small Color Screen

2.8 inch TFT LCD Display

Place of Origin:

Shenzhen, China

Brand Name:

Polcd

Certification:

RoHS, ISO9001

Model Number:

P028HK9853-24P

Request A Quote

Product Details

Screen Size:

2.8 Inch

Resolution:

240RGB(H)x320(V)

Brightness (cd/m²):

200 Nit

Interface:

4wire SPI

Driver Ic:

JD9853

Display Area:

43.20(H)x57.60(V)

Payment & Shipping Terms

Minimum Order Quantity

1 piece

Price

Please contact us for latest price

Packaging Details

20 cm * 30 cm * 40 cm

Delivery Time

1~7 working days

Payment Terms

T/T, L/C, Credit card, PayPal

Supply Ability

500,000 piece per week

Polcd 3.5 Inch IPS Viewing Angle 320x480 TFT Display Mipi Interface 3.5'' LCD Screen Modules

Get Best Price

Video

Polcd 3.5'' 3.5 Inch SPI Interface 320x480 Resolution ST7796U Driver IC IPS TFT LCD Display Module

Get Best Price

Video

Polcd Round 240*240 1.28 1.3 Inch touch Tft Lcd Display SPI Interface GC9A01 Driver IC IPS Screen

Get Best Price

Video

Polcd 1.28 Inch IPS Circular LCD Display 240xRGBx240 Resolution Customized TFT LCD Module for Smart Watches

Get Best Price

00-86-13714394335

anna@polcd.com

86-755-21011746

Contact Now

Product Description

Parameter:

Model	P028HK9853-24P
Screen Size	2.8 inch
Number of Pixel	240RGB(H)x320(V)
Display area	43.20(H)x57.60(V)mm
Pixel pitch	0.180(H)x0.180(V)mm
Pins	24 pins
Outline Dimension	50.00x69.20x2.30mm
Pixel arrangement	RGB Vertical Stripe
Display mode	Normally black
Viewing Direction(eye)	ALL
Gray inversion direction	--
Display Color	262K
Luminance(cd/m2)	200 nit
Contrast Ratio	1200:1
Surface treatment	--
Interface	4-line SPI
Back-light	LED Side-light type
Drive IC	JD9853
Operation Temperature	-20~70℃
Storage Temperature	-30~80℃

Polcd 2.8 inch TFT 240*320 Small Color Screen JD9853 Drive IC Spi interface IPS TFT LCD Display 0

Polcd 2.8 inch TFT 240*320 Small Color Screen JD9853 Drive IC Spi interface IPS TFT LCD Display 1

Polcd 2.8 inch TFT 240*320 Small Color Screen JD9853 Drive IC Spi interface IPS TFT LCD Display 2

Polcd 2.8 inch TFT 240*320 Small Color Screen JD9853 Drive IC Spi interface IPS TFT LCD Display
