Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module

Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module

Place of Origin:

Shenzhen, China

Brand Name:

Polcd

Certification:

RoHS, ISO9001

Model Number:

P020H025-IPS

Contact Us

Request A Quote
Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module
Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module
Product Details
Size (inch):
2 Inch
Resolution:
240*320
Active Area (W * H ):
30.60(H)x40.80(V)mm
Brightness (cd/m²):
260 Nit
Interface:
4W SPI
Driver Ic:
ST7789V
Payment & Shipping Terms
Minimum Order Quantity
1 piece
Price
Please contact us for latest price
Packaging Details
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Delivery Time
1-7 working days
Payment Terms
T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram
Supply Ability
40,000 PCS per day
RELATED PRODUCTS
Good price Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module online Video

Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module

Get Best Price
Good price Polcd 350 Nit Small TFT Display ILI9341V MCU interface 3.2 Video

Polcd 350 Nit Small TFT Display ILI9341V MCU interface 3.2" Tft Display

Get Best Price
Good price 2.8 Inch 178° Ips Tft Capacitive Touch Screen Full View Angle Spi Interface online Video

2.8 Inch 178° Ips Tft Capacitive Touch Screen Full View Angle Spi Interface

Get Best Price
Good price Polcd 240x320 Led Backlit Tft Lcd Display 2.4 Inch LCM 260 Nit Brightness Lcm Panel online Video

Polcd 240x320 Led Backlit Tft Lcd Display 2.4 Inch LCM 260 Nit Brightness Lcm Panel

Get Best Price
CONTACT US
00-86-13714394335
anna@polcd.com
86-755-21011746
Contact Now
Product Description

Product description:

The 2 inch TFT LCD is a versatile display technology that offers high resolution, accurate color representation, low power consumption, and a compact size. It is a popular choice for use in handheld devices like digital cameras, portable media players, and gaming devices.


Parameter:

Model P020H025-IPS
Screen Size 2.0 inch
Number of Pixel 240RGB(H)x320(V)
Display area 30.60(H)x40.80(V)mm
Pixel pitch 0.0425(H)x0.1275(V)mm
Outline Dimension 34.60x47.80x1.92mm
Pixel arrangement RGB Vertical Stripe
Pins 12 Pins
Display mode Normally Black
Viewing Direction(eye) ALL
Display Color 262K
Luminance(cd/m2) 260 nit
Contrast Ratio 800:1
Interface 4W SPI
Back-light LED Side-light type
Drive IC ST7789V
Operation Temperature -20~70℃
Storage Temperature -30~80℃

Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module 0Polcd 2'' 2 Inch 240x320 Resolution ST7789V SPI Interface IPS TFT LCD Screen Lcd Display Module 1
