Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module

Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module

Place of Origin:

Shenzhen, China

Brand Name:

Polcd

Certification:

RoHS, ISO9001

Model Number:

P028B140-IPS-CTP

Contact Us

Request A Quote
Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module
Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module
Product Details
Resolution:
240x320
Interface:
3W 18Bit RGB
Driver IC:
ST7789V
Brightness (cd/m²):
500 Nit
Viewing Angle:
IPS All View Angle
Display Area:
43.20(H)x57.60(V)mm
Payment & Shipping Terms
Minimum Order Quantity
1 piece
Price
Please contact us for latest price
Packaging Details
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Delivery Time
1-7 working days
Payment Terms
T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram
Supply Ability
25,000 PCS per day
RELATED PRODUCTS
Good price Polcd 2.8 Inch Tft Touch Lcd Display Module 240*320 RGB Interface Color Touch Small Screen online Video

Polcd 2.8 Inch Tft Touch Lcd Display Module 240*320 RGB Interface Color Touch Small Screen

Get Best Price
Good price Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module online Video

Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module

Get Best Price
Good price Polcd LCD Manufacturer 4.5 inch 480x854 Gc9503v Rgb interface High Brightness IPS TFT Screen Panel Display online Video

Polcd LCD Manufacturer 4.5 inch 480x854 Gc9503v Rgb interface High Brightness IPS TFT Screen Panel Display

Get Best Price
Good price Polcd 2.8 Inch LCM Module 240x320 Resolution MCU interface ST7789V 24pin IPS TFT LCD Screen Display online Video

Polcd 2.8 Inch LCM Module 240x320 Resolution MCU interface ST7789V 24pin IPS TFT LCD Screen Display

Get Best Price
Contact Us
00-86-13714394335
anna@polcd.com
86-755-21011746
Contact Now
Product Description

Description of 2.8 inch TFT LCD :

2.8 inch TFT LCD (Thin Film Transistor Liquid Crystal Display) is a small-size display module that uses TFT technology to provide high-quality color images and videos. The display has a diagonal screen size of 2.8 inch and a resolution of 240x320 pixels, providing clear and sharp images with accurate color representation.


Parameter:

ItemSpecification
ModelP028B140-IPS-CTP
Screen Size2.8 inch
Number of Pixel240RGB(H)x320(V)
Display area43.20(H)x57.60(V)mm
Pixel pitch0.180(H)x0.180(V)mm
Pins40 pins
Outline Dimension53.00x77.00x4.35mm
Pixel arrangementRGB Vertical Stripe
Display modeNormally Black
Viewing Direction(eye)ALL
Gray inversion direction--
Display Color262K
Luminance(cd/m2)500 nit
Contrast Ratio1200:1
Surface treatment--
Interface3W 18Bit RGB
Back-lightLED Side-light type
Drive ICST7789V
CTP ICCST3240
Operation Temperature-20~70℃
Storage Temperature-30~80℃


Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module 0

Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module 1Polcd Custom Rgb Interface 2.8 Inch Small Color TFT Display Panel Touch Screen LCD Module 2
