Polcd 3.5 inch 320*480 LCD Display ILI9488 build-in Capacitive Touch Panel High Brightness TFT LCD

Polcd 3.5 inch 320*480 LCD Display ILI9488 build-in Capacitive Touch Panel High Brightness TFT LCD

Place of Origin:

Shenzhen, China

Brand Name:

Polcd

Certification:

RoHS, ISO9001

Model Number:

P035C013-V6-CTP-911

Contact Us

Request A Quote
Product Details
Screen Size:
3.5 Inch
Resolution:
320*480
Brightness (cd/m²):
300 Nit
Interface:
MCU 8/16bit SPI 3/4wire
Driver Ic:
ILI9488
Display Area:
48.96(H)x73.44(V)mm
Payment & Shipping Terms
Minimum Order Quantity
1 piece
Price
Please contact us for latest price
Packaging Details
20 cm * 30 cm * 40 cm
Delivery Time
1~7 working days
Payment Terms
T/T, L/C, Credit card, PayPal
Supply Ability
500,000 piece per week
Product Description

Parameter:

Model P035C013-V6-CTP-911
Screen Size 3.5 inch
Number of Pixel 320RGB(H)x480(V)
Display area 48.96(H)x73.44(V)mm
Pixel pitch 0.153(H)x0.153(V)mm
Pins 40 pins
Outline Dimension 54.48x84.71x3.40mm
Pixel arrangement RGB Vertical Stripe
Display mode Normally white
Viewing Direction(eye) 12 0’CLOCK
Gray inversion direction --
Display Color 262K
Luminance(cd/m2) 300 nit
Contrast Ratio 500:1
Surface treatment --
Interface MCU 8/16bit SPI 3/4 wire
Back-light LED Side-light type
Drive IC ILI9488
CTP IC GT911
Operation Temperature -20~70℃
Storage Temperature -30~80℃



Polcd 3.5 inch 320*480 LCD Display ILI9488 build-in Capacitive Touch Panel High Brightness TFT LCD 0Polcd 3.5 inch 320*480 LCD Display ILI9488 build-in Capacitive Touch Panel High Brightness TFT LCD 1
