Place of Origin:
Shenzhen, China
Brand Name:
Polcd
Certification:
RoHS, ISO9001
Model Number:
P043B037-IPS
Contact Us
Video
Video
Parameter:
| Model | P043B037-IPS |
| Screen Size | 4.3 inch |
| Number of Pixel | 480RGB(H)x272(V) |
| Display area | 95.04(H)x53.86(V)mm |
| Pixel pitch | 66(H)x3x198(V)mm |
| Pins | 20 pins |
| Outline Dimension | 105.46x67.10x3.00mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally Black |
| Viewing Direction(eye) | ALL |
| Display Color | 16.7M |
| Luminance(cd/m2) | 400 nit |
| Contrast Ratio | 1000:1 |
| Interface | MCU 8/16bit SPI 3w/4w |
| Back-light | LED Side-light type |
| Drive IC | NV3041A-01 |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
