Place of Origin:
Shenzhen, China
Brand Name:
Polcd
Certification:
RoHS, ISO9001
Model Number:
P023H022
Contact Us
This Medical LCD Display is a color-active matrix thin-film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. If your product requires a size 2.31 inch then our lcd is just what you need. Improve your product design by adding our 320 * 240 resolution product. QC department measured the luminance is 300 nits under normal operating.
P/N | P022H022 |
Size(inch) | 2.31 |
Resolution | 320*240 |
Active Area(mm) | 46.75*35.06 |
Pixel pitch(um) | 146.1*146.1 |
Outline Dimension(mm) | 50.96*45.80*2.40 |
Pixel arrangement | RGB Vertical Stripe |
Display Mode | Normally Black |
Viewing Angle | 6 0'CLOCK |
Display colors | 262K |
Brightness (cd/m²) |
300 |
Contrast Ratio | 600:1 |
Interface | RGB 18bit |
Back-light | LED Side-light type |
Driver Ic | ILI9342C |
Operation Temperature(°C) | -20~70 |
Storage Temperature(°C) | -30~80 |
Response time(ms) | 35 |
Pin Number | 40 |
This type of RGB 18bit can be suitable for a variety of scenarios. From the datasheet we can know the driver of the LCD is is ILI9342C. THE lowest operating temperature can reach -20°C (-4°F) and highest is 70°C (158°F).
Q: I cannot find the size, the interface or the FPC I need, is it possible for customization?
A: Of course you can customize. Just tell us what you need. However, TFT LCD module has different tooling cost which includes FPC, Touch screen, backlight, bezel and so on.
Q: Where can I get the datasheet, initialization code, product drawings, test reports and other technical files?
A: Please contact our sales and we will provide any files if you need.
Q: How long can I get the goods?
A: It depends on the quantity. Our inventory is mainly raw materials, semi-finished and a small number of finished products. Samples available in stock will be sent in 3 days; Small batch delivery takes 15-20 working days include producing; Large batch delivery takes 20-30 working days. We will list the time cost for you before order.
Q: What kind of packaging? Will the transport process be damaged?
A: Packed in anti-static bags with foam box to ensure safety in transportation.
