Name: Polcd Custom 2.4 Inch Lcd Capacitive Touch Screen Display Panel 240*320 SPI Interface Tft Screen Module
Brand: Shenzhen P&O Technology Co., Ltd
SKU: P024C128-CTP
Availability: InStock

Home > Products > TFT LCD Module >

Polcd Custom 2.4 Inch Lcd Capacitive Touch Screen Display Panel 240*320 SPI Interface Tft Screen Module

2.4 inch TFT LCD touch screen

SPI interface LCD display panel

capacitive touch screen module

Place of Origin:

Shenzhen, China

Brand Name:

Polcd

Certification:

RoHS, ISO9001

Model Number:

P024C128-CTP

Request A Quote

Product Details

Resolution:

240x320

Interface:

4W SPI

Driver IC:

ST7789V

Brightness (cd/m²):

260 Nit

Viewing Angle:

12 0'CLOCK

Display Area:

36.72(H)x48.96(V) Mm

Payment & Shipping Terms

Minimum Order Quantity

1 piece

Price

Please contact us for latest price

Packaging Details

FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm

Delivery Time

1-7 working days

Payment Terms

T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram

Supply Ability

40,000 PCS per day

Polcd 2.4 Inch 240x320 ST7789V Mcu Interface Full Viewing Angle IPS 2.4" Tft Lcd Module

Get Best Price

Video

Polcd 2.4 Inch Touch Screen Module ST7789V IC 240x320 Resolution 2.4" TFT LCD Display

Get Best Price

Video

Polcd Custom 2.4 Inch Lcd Capacitive Touch Screen Display Panel 240*320 Mcu Interface Tft Screen Module

Get Best Price

Video

Polcd Custom 2.4 Inch Lcd Capacitive Touch Screen Display Panel 240*320 SPI Interface Tft Screen Module

Get Best Price

00-86-13714394335

anna@polcd.com

86-755-21011746

Contact Now

Product Description

Parameter:

Model	P024C128-CTP
Screen Size	2.4 inch
Number of Pixel	240RGB(H)x320(V)
Display area	36.72(H)x48.96(V)mm
Pixel pitch	51(H)x153(V)um
Pins	16 pins
Outline Dimension	42.72x60.26x3.35mm
Pixel arrangement	RGB Vertical Stripe
Display mode	Normally White
Viewing Direction(eye)	12 0'CLOCK
Display Color	262K
Luminance(cd/m2)	260 nit
Contrast Ratio	250:1
Interface	4W SPI
Back-light	LED Side-light type
Drive IC	ST7789V
CTP IC	FT6336U
Operation Temperature	-20~70℃
Storage Temperature	-30~80℃

Advantages

1.High-quality display: offer high-quality display performance with a resolution of up to 240x320 pixels, providing clear and sharp images and videos.

2.Wide viewing angle: TFT LCD technology typically has a wide viewing angle, allowing for clear viewing from different angles without distortion or color shift.

3.Color display: can display up to 262,144 colors, providing accurate color representation and making it ideal for displaying images and videos.

4.Touch screen support: support capacitive touch screen input, allowing users to select, slide, and zoom with their fingers.

5.Low power consumption: it has low power consumption, which is important for devices that run on battery power.

6.Durability: TFT LCD modules are durable and can withstand shock and vibration, making them suitable for use in various applications, including handheld devices, automotive displays, and medical equipment.

7.Customization: can be customized to meet specific application requirements, including different sizes, resolutions, and features.

Polcd Custom 2.4 Inch Lcd Capacitive Touch Screen Display Panel 240*320 SPI Interface Tft Screen Module 0
