Polcd Liquid Crystal Display 2.0 Inch Mini Full Color ST7789 MCU IPS Full Angle View 240x320 TFT LCD Module

Polcd Liquid Crystal Display 2.0 Inch Mini Full Color ST7789 MCU IPS Full Angle View 240x320 TFT LCD Module

240x320 TFT LCD Module

Full Color TFT LCD Module

2.0 Inch TFT LCD Module

Place of Origin:

Shenzhen, China

Brand Name:

Polcd

Certification:

RoHS, ISO9001

Model Number:

P020H030-IPS

Contact Us

Request A Quote
Product Details
Resolution:
240x320
Interface:
8 Bit MCU
Driver IC:
ST7789V
Brightness (cd/m²):
300 Nit
Viewing Angle:
IPS All Viewing Angle
Display Area:
30.60(H)x40.80(V)mm
Payment & Shipping Terms
Minimum Order Quantity
1 piece
Price
Please contact us for latest price
Packaging Details
FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm
Delivery Time
1-7 working days
Payment Terms
T/T, L/C, Credit card, PayPal, D/A, D/P, Western Union, MoneyGram
Supply Ability
25,000 PCS per day
Product Description

Parameter:

Model P020H030-IPS
Screen Size 2.0 inch
Number of Pixel 240RGB(H)x320(V)
Display area 30.60(H)x40.80(V)mm
Pixel pitch 0.0425(H)x0.1275(V)mm
Outline Dimension 36.00x51.90x2.55mm
Pixel arrangement RGB Vertical Stripe
Pins 20 Pins
Display mode Normally Black
Viewing Direction(eye) ALL
Display Color 262K
Luminance(cd/m2) 300 nit
Contrast Ratio 800:1
Surface treatment --
Interface 8 bit MCU
Back-light LED Side-light type
Drive IC ST7789V
Operation Temperature -20~70℃
Storage Temperature -30~80℃



Features

8Bit MCU interface.



Applications

1. MPOS Device.

2. Personal Navigation Device.

3. Other devices which require high quality displays.
