Place of Origin:
Shenzhen, China
Brand Name:
Polcd
Certification:
RoHS, ISO9001
Model Number:
P024C128-CTP
Contact Us
Video
Video
Parameter:
| Item | Specification |
| Model | P024C128-CTP |
| Screen Size | 2.4 inch |
| Number of Pixel | 240RGB(H)x320(V) |
| Display area | 36.72(H)x48.96(V)mm |
| Pixel pitch | 51(H)x153(V)um |
| Pins | 16 pins |
| Outline Dimension | 42.72x60.26x3.35mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally White |
| Viewing Direction(eye) | 12 0'CLOCK |
| Gray inversion direction | -- |
| Display Color | 262K |
| Luminance(cd/m2) | 260 nit |
| Contrast Ratio | 250:1 |
| Surface treatment | -- |
| Interface | 4W SPI |
| Back-light | LED Side-light type |
| Drive IC | ST7789V |
| CTP IC | FT6336U |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
2.4 inch TFT LCD modules have several advantages that make them a popular choice for various electronic devices.Some of the key advantages include:
1.High-quality display: 2.4 inch TFT LCD modules offer high-quality display performance with a resolution of up to 240x320 pixels, providing clear and sharp images and videos.
2.Wide viewing angle: TFT LCD technology typically has a wide viewing angle, allowing for clear viewing from different angles without distortion or color shift.
3.Color display: The TFT LCD module can display up to 262,144 colors, providing accurate color representation and making it ideal for displaying images and videos.
4.Touch screen support: Many 2.4 inch TFT LCD modules support capacitive touch screen input, allowing users to select, slide, and zoom with their fingers.
5.Low power consumption: TFT LCD technology typically has low power consumption, which is important for devices that run on battery power.
6.Durability: TFT LCD modules are durable and can withstand shock and vibration, making them suitable for use in various applications, including handheld devices, automotive displays, and medical equipment.
7.Customization: 2.4 inch TFT LCD modules can be customized to meet specific application requirements, including different sizes, resolutions, and features.
