Name: Polcd 2.4 Inch St7789v Drive ic 8080 MCU High Brightness TFT Display
Brand: Shenzhen P&O Technology Co., Ltd
SKU: P024C026
Availability: InStock

Home > Products > TFT LCD Module >

Polcd 2.4 Inch St7789v Drive ic 8080 MCU High Brightness TFT Display

2.4 Inch Ips St7789v

Ips St7789v 8080 MCU

8080 MCU High Brightness TFT Display

Place of Origin:

Shenzhen, China

Brand Name:

Polcd

Certification:

RoHS, ISO9001

Model Number:

P024C026

Request A Quote

Product Details

P/N:

P024C026

Size (inch):

2.4

Resolution:

240*320

Brightness (cd/m²):

320

Interface:

8080 MCU 16bits

Driver Ic:

ST7789V

Payment & Shipping Terms

Minimum Order Quantity

1 piece

Price

Please contact us for latest price

Packaging Details

FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm

Delivery Time

1-7 working days

Payment Terms

T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram

Supply Ability

40,000 PCS per day

Polcd ILI9488 Display Tft Lcd 12 0'CLOCK 3.5 Tft Lcd Raspberry Pi 48.96mm

Get Best Price

Video

Polcd 12 O'CLOCK 3.2 Inch TFT Display ILI9341V TFT LCD Module 240x320

Get Best Price

Video

Polcd 350nit 3.2 Inch Raspberry Pi Display ILI9341V Sunlight Readable Lcd Display

Get Best Price

Video

Polcd Custom 2.4 Inch 20 Pin Tft Lcd 240x320 Transflective Color Screen with ST7789T3 Lcd Display

Get Best Price

00-86-13714394335

anna@polcd.com

86-755-21011746

Contact Now

Product Description

Description:

2.4 inch TFT LCD with MCU interface is a display module that is designed to be controlled by a microcontroller unit (MCU).

Parameter:

Model	P024C026
Screen Size	2.4 inch
Number of Pixel	240RGB(H)x320(V)
Display area	36.72(H)x48.96(V)mm
Pixel pitch	51(H)x153(V)um
Pins	40 pins
Outline Dimension	42.72x60.26x2.30mm
Pixel arrangement	RGB Vertical Stripe
Display mode	Normally White
Viewing Direction(eye)	12 0'CLOCK
Display Color	262K
Luminance(cd/m2)	260 nit
Contrast Ratio	250:1
Interface	MCU 16bits
Back-light	LED Side-light type
Drive IC	ST7789V
Operation Temperature	-20~70℃
Storage Temperature	-30~80℃

Polcd 2.4 Inch St7789v Drive ic 8080 MCU High Brightness TFT Display 0
