Name: Polcd ILI9488 Display Tft Lcd 12 0'CLOCK 3.5 Tft Lcd Raspberry Pi 48.96mm
Brand: Shenzhen P&O Technology Co., Ltd
SKU: P035C018-TP
Availability: InStock

Home > Products > TFT LCD Module >

Polcd ILI9488 Display Tft Lcd 12 0'CLOCK 3.5 Tft Lcd Raspberry Pi 48.96mm

ILI9488 Display Tft Lcd

Display Tft Lcd 12 0'CLOCK 3.5

3.5 Tft Lcd Raspberry Pi 48.96mm

Place of Origin:

Shenzhen, China

Brand Name:

Polcd

Certification:

RoHS, ISO9001

Model Number:

P035C018-TP

Request A Quote

Product Details

Size (inch):

3.5

Resolution:

320*480

Brightness (cd/m²):

300 Nit

Interface:

MCU 8/16bit RGB 18bit SPI 3/4wire

Driver Ic:

ILI9488

Payment & Shipping Terms

Minimum Order Quantity

1 piece

Price

Please contact us for latest price

Packaging Details

FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm

Delivery Time

1-7 working days

Payment Terms

T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram

Supply Ability

40,000 PCS per day

Polcd ILI9488 Display Tft Lcd 12 0'CLOCK 3.5 Tft Lcd Raspberry Pi 48.96mm

Get Best Price

Video

Polcd 12 O'CLOCK 3.2 Inch TFT Display ILI9341V TFT LCD Module 240x320

Get Best Price

Video

Polcd 350nit 3.2 Inch Raspberry Pi Display ILI9341V Sunlight Readable Lcd Display

Get Best Price

Video

Polcd Custom 2.4 Inch 20 Pin Tft Lcd 240x320 Transflective Color Screen with ST7789T3 Lcd Display

Get Best Price

00-86-13714394335

anna@polcd.com

86-755-21011746

Contact Now

Product Description

New published TFT Touch Screen for commercial and industrial use. Our TFT LCD has a 3.5 inch diagonally. The resolution of our tft lcd is 320 * 480. The normal brightness is 300 nits under the test of laboratory.

Parameter:

Model	P035C018-TP
Screen Size	3.5 inch
Number of Pixel	320RGB(H)x480(V)
Display area	48.96(H)x73.44(V)mm
Pixel pitch	0.153(H)x0.153(V)mm
Pin	50 pin
Outline Dimension	54.48x84.71x2.25mm
Pixel arrangement	RGB Vertical Stripe
Display mode	Normally White
Viewing Direction(eye)	12 0'CLOCK
Display Color	262k
Luminance(cd/m²)	300 nit
Contrast Ratio	500:1
Interface	MCU 8/16bit RGB 18bit SPI 3/4wire
Back-light	LED Side-light type
Drive IC	ILI9488
Operation Temperature	-20~70℃
Storage Temperature	-30~80℃

The Interface of this LCD is MCU 16bit. We can also customize other types of interfaces and FPCs for you. The ILI9488 driver IC provides on-chip storage and power system. If your products need to work under a temperature from -20°C to 70°C, then it can meet your needs.

Polcd ILI9488 Display Tft Lcd 12 0'CLOCK 3.5 Tft Lcd Raspberry Pi 48.96mm 0

Q: Can we customize product? What cost will be included?
A: The product can be customized. However, TFT LCD module has different tooling cost which includes FPC, Touch screen, backlight, bezel and so on.

Q: What about payment terms?
A: PayPal and credit card can be accepted for sample, T/T paid for mass order. Advance payment percentage can be discussed.

Q: What is your delivery method?
A: EXW Shenzhen by DHL/ UPS/ FedEx/ TNT and any other method you want. Or ship the goods to your forwarder in China mainland and Hong Kong.

Q: Can I trust the quality? We want good quality first.
A: Our company has a professional Quality Control Department, and all products are 100% inspected prior to ship. We welcome all the customers from the wolrd visiting our factory for checking any time.
