Place of Origin:
Shenzhen, China
Brand Name:
Polcd
Certification:
RoHS, ISO9001
Model Number:
P028B123-10-IPS-CTP
Contact Us
Video
Video
TFT Display Description:
This is a 2.8 inch TFT LCD display with IPS technology and a capacitive touch panel (CTP). It provides clear and accurate visuals with responsive touch control, making it ideal for various applications, from consumer electronics to industrial equipment.
Parameter:
| Model | P028B123-10-IPS-CTP |
| Screen Size | 2.8 inch |
| Number of Pixel | 240RGB(H)x320(V) |
| Pin | 10 pin |
| Display area | 43.20(H)x57.60(V)mm |
| Pixel pitch | 0.180(H)x0.180(V)mm |
| Outline Dimension | 50.00x69.20x3.10mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally Black |
| Viewing Direction(eye) | ALL |
| Display Color | 262K |
| Luminance(cd/m2) | 300 nit |
| Contrast Ratio | 1200:1 |
| Interface | 4wire SPI |
| Back-light | LED Side-light type |
| Drive IC | ST7789V |
| Operation Temperature | -20~70 ℃ |
| Storage Temperature | -30~80 ℃ |
Product introduction
This 2.8-inch TFT LCD display with IPS technology and capacitive touch panel (CTP) provides clear and accurate visuals with responsive touch control. Its compact size and versatile functionality make it an ideal choice for various applications, from consumer electronics to industrial equipment. With its advanced features and reliable performance, this display is an excellent choice for manufacturers seeking high-quality display solutions with touch control capabilities.
